Galvanized tube steel Transmission Power Pole for 69KV Transmission Line

Galvanized tube steel Transmission Power Pole for 69KV Transmission Line
Galvanized tube steel Transmission Power Pole for 69KV Transmission Line Galvanized tube steel Transmission Power Pole for 69KV Transmission Line Galvanized tube steel Transmission Power Pole for 69KV Transmission Line Galvanized tube steel Transmission Power Pole for 69KV Transmission Line Galvanized tube steel Transmission Power Pole for 69KV Transmission Line

Large Image :  Galvanized tube steel Transmission Power Pole for 69KV Transmission Line

Product Details:
Place of Origin: China
Brand Name: JSBS
Certification: ISO9001:2008
Model Number: BS/PT - 06
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Use sack package the poles or as customer’s request.
Delivery Time: 15 - 25 work days
Payment Terms: D/P, L/C, T/T, Western Union
Supply Ability: 2500 Ton per month
Detailed Product Description
Height: ≥ 15 M Shape: Dodecagonal
Material: Steel Q345 Connection: Slip Joint
Zinc Coating: Min 86μm Galvanized: ASTM A 123
Welding: AWS D1.1 Finishing: Hot Dip Galvanized
High Light:

steel transmission poles

,

electrical utility pole

Dodecagonal Electrical Transmission Power Steel Pole for 69KV Transmission Line

Specification


1) Steel materials conform to ASTM A36 with Q235(S235,SS400),Q345(S355JR), Q460,etc

2) Welding: Welding complies with CSA and AWS, AWS D1.1 standard.

3) Finish: Hot-dip galvanized in accordance with ASTM A123.

4) Pole Height: Transmission pole ≥ 15M

5) Pole shape: Conical, Round, Polygonal---Octagonal, Dodecagonal, Hexadecagonal, etc

6) Type: Straight Pole ,Tensile Pole ,Turn Pole (Double-loop corner pole, Single or double loops/circuit pole,
     single or double tensile/terminal/straight pole, etc)

7) Surface hot-dip-galvanized and sometimes with Bituminous Painting as customer's request.

8) Resistant: against earthquake of 8.8 grade. Wind speed as design.

9) Quality Standard: ISO9001:2000,AAA credit rating

10) Easy install and maintenance


11) Packages: Normally covered by sack or as customer’s requirement.


12) Voltage:10-550KV


Description


Our Transmission steel poles, being manufactured from steel sheet that has been subjected to hydraulic pression and longitudinal welding, has a tapered tubular structure with a multilateral cross section. To achieve a proper height, steel poles can be assembled by insert mode or flange mode at the installation site.

The hot dip galvanization technique could protect steel pole from corrosion for as long as 50 years
As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole could be utilize to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.


Accessories:

1. Pole
2. Base Plate
3. Pole Top Cap
4. Butt Bearing Plate
5. Holes
6. CrossArm
7. Grounding Nut & Bolts
8. Anchor Bolts
9. Climbing Rungs
10. Identification Plate
11. Bituminous Painting if needed
12. Hot dip galvanized.



Production Line


  • Raw material test
  • Cutting
  • Bending
  • Welding (longitudinal )
  • Dimension verify
  • Flange welding
  • Hole drilling
  • Calibration
  • Deburr
  • Galvanization or powder coating or Bituminous painting
  • Recalibration
  • Packages



Parameter


Products
  • Dodecagonal Electrical Transmission Power Steel Pole for 69KV Transmission Line
Type
  • Suspension Pole , Tensile Pole , Strain Pole , Angle Pole , etc
Voltage Grade



  • 10~500KV (10KV, 13.8KV,33KV, 35KV, 66KV, 69KV , 110KV,132KV, 220KV, 230KV, 330KV, 500KV or Others )
Height
  • ≥ 15M .
Shape
  • Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc).
Material
  • Hot Roll Steel Sheet Q345, GR50 which equivalent to S355JR.
  • Min Yield Stree 345 Mpa
  • Tensile Strength 470 Mpa ~ 630 Mpa
Wall thickness
  • 3 ~ 20mm
Once Forming
  • 14m Once forming without joint
  • 40GP, 40HQ container Length is 12m , so the poles will be or more than 2 segments if longer than 12m.
Welding
  • Welding complies with AWS D1.1 standard.
  • CO2 welding or submerged arc auto methods
  • No fissure, scar, overlap, layer or other defects
  • Internal and external welding
  • Ensure 100% complete penetration welds.
Joint
  • Joint with insert mode, flange mode.
Base plate
  • Base plate is square/round/Polygon with slotted holes for anchor bolts installation.
Galvanization
  • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123.
Warrantly
  • More than 25 years, it is according to installing environment


Galvanized tube steel Transmission Power Pole for 69KV Transmission Line 0


Galvanized tube steel Transmission Power Pole for 69KV Transmission Line 1


Galvanized tube steel Transmission Power Pole for 69KV Transmission Line 2

Terms and Conditions
1. Price Term: EXW, FOB, CFR or CIF.

Ø EXW: Poles Cost
Ø FOB : Pole Cost + Land Transportation + Fee on Port
Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight
Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.

2. MOQ: One 40FT Container.
3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other
    payment way can be negotiated.
4. Delivery Time: 15 working days per container after PI / drawing / prepayment confirmed.
5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom,or according to clients’
    requirement.


Factory Profile
Jiangsu Baojuhe Science and Technology Co.,Ltd. (previous name Jiangsu Bosheng Steel Poles Co.,Ltd.) is located in Heqiao Town Industrial Zone, Yixing District, Wuxi City, Jiangsu Province, China.

Baojuhe is the specialized manufacturer of various steel poles and steel components including street lighting poles, electric power poles, traffic signal poles, flag poles, wind power poles and microwave communication towers, etc.

Through Shanghai Port, which is one of the largest ports in China, we export poles to South America, Middle East, Africa, Australia, Philippines and other countries.

Galvanized tube steel Transmission Power Pole for 69KV Transmission Line 3
