Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole

Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole
Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole

Large Image :  Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole

Product Details:
Place of Origin: China
Brand Name: JSBS
Certification: ISO9001:2008
Model Number: BS/EP - 03
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiation
Packaging Details: Use sack package the poles or straw or wood or steel strap, etc
Delivery Time: 15 working days after received the downpayment
Payment Terms: T/T OR LC
Supply Ability: 2000Ton per month
Detailed Product Description
Product Name: Electric Power Poles Material: Steel
Min Yield Stress: 345 Mpa Section: 2
Surface Trement: Hot Dip Galvanized. Galvanized: ASTM A 123
Shape: Polygonal / Round Voltage: 132 KV
High Light:

power transmission poles

,

composite utility poles



HDG Polygonal Shape Electrical Power Steel Pole for 132 KV Transmission Line




Specification

Steel Yield Strength(MPa) standard Standard Title Metallic element Content
main ingredient Q345 345 for Thickness<=16

GB/T 1591-2008

(ASTM A572/A572M-15 ,EN10025 S355N)

High strength low alloy structural steels C ≤0.20
Mn ≤1.70
Si ≤0.50
Accessories Q235 235

GB/T 700-2006

(ASTM A283 Gr.B ,EN10025 S235JR)

Carbon structural steels
P ≤0.035
S ≤0.035





Welding Standard Standard Title

Pole shafts&multi-sided tubular

Cross arms&all accessories

AWS D1.1/D1.1M:2010 Structural Welding Code-Steel
Welding wire AWS D1.1/D1.1M:2010 Structural Welding Code-Steel





Hot dip galvanizing Standard Steel thickness/mm Mean coating thickness/μm Metallic element Content
Pole shafts,cross arms&bolted on accessories ASTM A123/A123M-15 AS/NZS 4680 >6 85

Mn



0.25%-0.40%



<3-6 70
1.5-3 55

Cu



<0.15%



<1.5 55
Bolts,nuts&washers

GB/T 5267.3-2008

(ISO 10684-2004)

_____ ≥ 54 P

<0.025%



Foundation bolts ASTM A153/A153M-09 _____ ≥ 54

S



<0.03%









Description:



The HDG  Electrical Power Steel Pole is designed according to customer's request. For 132 KV transmission Line use. And with Base Plate use Anchor Bolts to Install. Two sections and use flange to connect each segment. It's hot dip galvanized in accordance with ASTM 123 and the zinc coating thickness is over 86 microns.





Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole 0



Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole 1



Accessories:



1. Pole

2. Base Plate

3. Pole Top Cap

4. Butt Strip Plate

5. Holes

6. CrossArm

7. Grounding Nut & Bolts

8. Anchor Bolts

9. Climbing Rungs

10. Identification Plate

11. Bituminous Painting if needed

12. Hot dip galvanized.





Transmission Line Electrical Power Pole HDG Polygonal Shape 132 KV Steel Pole 2





Through the efforts of the company staff, the support and cooperation from all over the world. Our factory has been exporting the steel poles to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container delivered in average every day.





Terms and Conditions


1. Price Term: EXW, FOB, CFR or CIF.



Ø EXW: Poles Cost

Ø FOB : Pole Cost + Land Transportation + Fee on Port

Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight

Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.



2. MOQ: One 40FT Container.


3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.


4. Delivery Time: 15 working days per container after PI / drawing / prepayment confirmed.


5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom,or according to clients’ requirement.
