12M-30M Height Dodecagonal Shape Q355 Material High Mast Pole and High Mast Light Pole for Telecommunication
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-h25 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 12M-30M | Shape: | Dodecagonal/ 12sides |
|---|---|---|---|
| Material: | Q355/Q420/Q460 | Thick: | 3.0mm-20.0mm |
| Surface: | Hot Dip Galvanized / Powder Coating | Galvanizing Thick: | Min Average Over 86 Microns |
| Applied: | Telecommunication High Mast | Warranty: | 5 Years |
| Highlight: | 12M-30M Height High Mast Pole,Dodecagonal Shape High Mast Light Pole,Q355 Material High Mast Steel Pole |
||
Product Description
Yixing Hongxin Illumination Facilities Co., Ltd. is a direct factory specializing in the manufacture of hot-dip galvanized high mast steel poles for both fixed-type and lift-type applications.
- Over 25 years of industry history
- 20 million RMB registered capital
- 15,000 square meter manufacturing facility
- Advanced machinery and equipment
- Experienced engineers and skilled workers
- Specialized in hot-dip galvanized steel poles
- Production capacity exceeding 1,000 tons per month
Raw materials are sourced from general-purpose steel grades per GB/T1591-2008, including Q255, Q355, Q420, and Q460 used in China.
| China – GB | America – ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade 50 [345] | S355JR |
| Q420 | Grade 60 [415] | S420NL |
| Q460 | Grade 65 [450] | S460NL |
Our factory operates advanced production lines and machinery, including two bending calibration machines, a hydraulic plate shearing machine, a cutting machine, a slitting machine, two gas welding machines, a hydraulic straightener, and more. All equipment ensures we produce steel poles of the highest quality.
| Height | From 12 meters to 50 meters |
|---|---|
| Suitable For | Airport, seaport, stadium, highway, roadway, supermarket, parking lot, etc. |
| Shape | Polygonal, conical, or columniform |
| Material | Normally Q345B/A572 with minimum yield strength ≥ 345 N/mm²; Q235B/A36 with minimum yield strength ≥ 235 N/mm²; as well as hot-rolled coil from ASTM A572 GR65, GR50, SS400 |
| Lamp Power | 20 W – 1000 W (HPS/MH), 220V (±10%) / 50Hz |
| Tolerance | According to client's requirement |
| Surface Treatment | Hot-dip galvanized following ASTM A123, or any other standard required by the client |
| Joint of Poles | Slip joint, flange connected |
| Standard | ISO 9001:2008 |
| Length per Section | Within 14 meters once forming |
| Welding Standard | AWS (American Welding Society) D 1.1 |
| Thickness | 3 mm to 20 mm |
| Production Process | Raw material test → Cutting → Bending → Welding (longitudinal) → Dimension verify → Flange welding → Hole drilling → Sample assemble → Surface clean → Galvanization or powder coating painting → Recalibration → Packaging |
| Packages | Packing with plastic paper or according to client's request |
To ensure quality, professional engineers inspect the poles throughout the manufacturing process and before delivery. We conduct lab tests, workload tests, steel thickness tests, galvanization thickness tests, and more.
We normally use 40HQ containers, and our port limit weight for a 40HQ container is 26 tons.
We are both a direct factory manufacturer and a trading company.
Our factory is located at Yinhe Road No.3, Wanshi Town, Jiangsu, China (mainland).
Our main products are electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, wind generation poles, and more.
Shanghai Port is our nearest port.
Normally 30% deposit with the balance by TT before shipping, or L/C.
Normally within 15 working days. If our factory is busy and your quantity is large, delivery takes approximately one month.
- EXW: Pole cost
- FOB: Pole cost + land transportation + port fees
- CFR: Pole cost + land transportation + port fees + sea freight
- CIF: Pole cost + land transportation + port fees + sea freight + insurance
