Dodecagonal 12.9M 17M 20M 25M 30M Lift Type Polygonal High Mast Steel Pole with Hot-dip Galvanization and White Powder Coating Surface
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-h1217 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 12M-40M | Shape: | Dodecagonal/ 12sides |
|---|---|---|---|
| Material: | Q355/Q420/Q460 | Thick: | 3.0mm-20.0mm |
| Surface: | Hot Dip Galvanized / Powder Coating | Galvanizing Thick: | Min Average Over 86 Microns |
| Applied: | Telecommunication High Mast | Warranty: | 5 Years |
| Highlight: | Hot-dip Galvanization Polygonal High Mast,Dodecagonal Shape High Mast Steel Pole,12M-40M Height Lighting High Mast |
||
Product Description
Dodecagonal 12.9M 17M 20M 25M 30M Lift Type Polygonal High Mast Steel Pole with Hot-dip Galvanization and White Powder Coating Surface
Hot-dip Galvanization and White Powder Coating Surface
Product Overview
Yixing Hongxin Illumination Facilities Co., Ltd. is a direct factory specialized in manufacturing hot dip galvanized high mast steel poles for both fixed type and lift type applications.
- Over 25 Years History
- 30 Million RMB Registered Capital
- 15,000 Square Meters Facility
- Advanced Machinery and Equipment
- Experienced Engineers and Skilled Workers
- Specialized in Hot Dip Galvanizing Steel Poles
- Production Capacity Over 1000 Tons Per Month
Material Specifications
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory owns advanced production lines and machines including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, and more. All equipment ensures we produce steel poles with the best quality.
Product Specifications
| Height | From 12 meter to 50 meter |
| Suitable For | Airport, seaport, stadium, highway, roadway, supermarket, parking lot, etc |
| Shape | Polygonal, Conical or Columniform |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm² As well as Hot rolled coil from ASTM A572 GR65, GR50, SS400 |
| Lamp Power | 20 W- 1000 W (HPS/MH) 220V (+-10%) /50Hz |
| Tolerance | According to client's requirement |
| Surface Treatment | Hot dip galvanized Following ASTM A 123, or any other standard by client required |
| Joint of Poles | Slip joint, flange connected |
| Standard | ISO 9001:2008 |
| Length per Section | Within 14 meter once forming |
| Welding Standard | AWS (American Welding Society) D 1.1 |
| Thickness | 3 mm to 20mm |
| Production Process | Raw material test → Cutting → Bending → Welding (longitudinal) → Dimension verify → Flange welding → Hole drilling → Sample assemble → Surface clean → Galvanization or powder coating painting → Recalibration → Packages |
| Packages | Packing with plastic paper or according to client's request |
Quality Inspection
To ensure the quality, we have professional engineers to inspect the poles during the manufacturing process and before delivery. We conduct Lab Tests, Workload Tests, Steel Thickness Tests, Galvanization Thickness Tests, and more.
Delivery Information
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
Frequently Asked Questions
1. Are you a manufacturer or a trading company?
We are the direct factory manufacturer and the trading company.
2. Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
3. What are your main products?
Our main products are electric poles, street lighting poles, high mast pole, telecommunication tower poles, traffic signal poles, wind generation poles, etc.
4. What's your nearest port?
Shanghai Port is our nearest port.
5. What's your payment term?
Normally 30% deposit and rest by TT before shipping. Or L/C.
6. What's your delivery time?
Normally within 15 working days. If our factory is busy and your quantity is large, then around one month.
7. What's your price term?
- EXW: Poles Cost
- FOB: Pole Cost + Land Transportation + Fee on Port
- CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
- CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
