35FT Octagonal Galvanized Steel Pole with 500KGF Load and Hot Dip Galvanized Surface for Distribution Line
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-35 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 35FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355 | Thick: | 2.75mm/ 3.0mm |
| Load: | 500KGF | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | 15kv Distribution Power Line |
| Warranty: | 5 Years | ||
| Highlight: | 35FT Height Galvanized Steel Pole,500KGF Load Metal Utility Pole,Hot Dip Galvanized Octagonal Steel Pole |
||
Product Description
35FT Octagonal Galvanized Steel Poles NEA Standard Poles with Climbing Rungs For Distribution Line
The Octagonal Galvanized 35FT Steel Poles are widely used in distribution power lines. With over 25 years of history, advanced machinery, experienced engineers, and skilled workers, Yixing Hongxin Illumination Facilities Co., Ltd. is a direct factory specialized in manufacturing these steel poles.
Height: 35FT
Material: Q355B/ASTM A36
Thickness: 2.75mm/3.0mm
Shape: Octagonal/8 sides
Design Load: 500KGF
Material: Q355B/ASTM A36
Thickness: 2.75mm/3.0mm
Shape: Octagonal/8 sides
Design Load: 500KGF
Material Specifications
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory owns advanced production lines and machinery including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, etc. All equipment ensures we produce steel poles with the best quality.
Finished Products Specifications
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
To ensure quality, we have professional engineers who inspect the poles during manufacturing and before delivery. Our inspection processes include Lab Test, Workload Test, Steel thickness Test, Galvanization thickness Test, and more.
Delivery Information
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
Frequently Asked Questions
1. Are you a manufacturer or a trading company?
We are the direct factory manufacturer and the trading company.
2. Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
3. What are your main products?
Our main products are electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, wind generation poles, etc.
4. What's your nearest port?
Shanghai Port is our nearest port.
5. What's your payment term?
Normally 30% deposit and rest by TT before shipping. Or L/C.
6. What's your delivery time?
Normally within 15 working days. If our factory is busy and your quantity is large, then around one month.
7. What's your price term?
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
