40FT Height Galvanized Octagonal Steel Pole with 500KGS Min Break Load and 3mm Thickness
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-40 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 40FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | ASTM A36 With 345Mpa Min Yield Strength | Thick: | 3.0mm |
| Load: | 500KGS | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Coating Over 86 Microns | Applied: | 15kv Distribution Power Line |
| Warranty: | 5 Years | ||
| Highlight: | 40FT Height Steel Utility Pole,500KGS Min Break Load Galvanized Steel Pole,3mm Thickness Octagonal Steel Pole |
||
Product Description
Our Hot-dip Galvanized NEA Standard 40FT Steel Poles are specifically designed for 15KV distribution power lines in the Philippines. With over 25 years of manufacturing experience, advanced machinery, and skilled workforce, Yixing Hongxin Illumination Facilities Co., Ltd. delivers high-quality steel poles directly from our factory.
Height: 40FT
Material: ASTM A36 with 345MPa min yield strength
Thickness: 3.0mm
Shape: Octagonal/8 sides
Design Load: 500KGS
Service Life: 50 years
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory utilizes advanced production equipment including two bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure the highest quality steel pole production.
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Our quality assurance process includes comprehensive inspections by professional engineers throughout manufacturing and before delivery. Testing protocols include Lab Tests, Workload Tests, Steel Thickness Tests, and Galvanization Thickness Tests.
We typically ship using 40HQ containers with a port limit weight of 26 tons per container.
- EXW: Poles Cost
- FOB: Pole Cost + Land Transportation + Fee on Port
- CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
- CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
