Hongxin 40FT Hot-dip Galvanized Steel Utility Pole with 345Mpa Yield Strength
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-40 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 40FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | 345Mpa | Thick: | 3mm |
| Load: | 500KGF | Segment: | 1 Segment |
| Surface: | Hot Dip Galvanized | Galvanizing Thick: | Min Average Over 86 Microns |
| Applied: | Power Line | Warranty: | 5 Years |
| Highlight: | 40FT Height Steel Utility Pole,Hot-dip Galvanized Steel Utility Pole,345Mpa Yield Strength Electric Steel Pole |
||
Product Description
Hongxin 40FT Octagonal Hot-dip Galvanized Electric Steel Utility Poles
Product Specifications
Height
40FT
Thickness
3mm
Segments
1 section
Design Load
500KGF
Surface Treatment
Hot Dip Galvanized (min 86 microns coating)
Manufacturing Process
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure the highest quality steel poles.
Material Specifications
Manufactured from high-quality raw materials conforming to GB/T1591-2008 standards, including Q255, Q355, Q420, and Q460 steel grades.
Product Range Specifications
Steel poles manufactured to National Electrification Administration (Philippines) specifications for distribution applications.
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
Professional engineers conduct comprehensive inspections throughout manufacturing and prior to delivery, including laboratory tests, workload tests, steel thickness verification, and galvanization coating thickness measurements.
Delivery Information
Standard delivery utilizes 40HQ containers with a maximum port weight limit of 26 tons per container.
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are both the direct factory manufacturer and a trading company.
Where is your company located?
Our factory is located at Yinhe Road No.3, Wanshi town, Jiangsu, China.
What are your main products?
Our main products include electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
What's your nearest port?
Shanghai Port is our nearest port.
What's your payment term?
Normally 30% deposit with the remainder by TT before shipping, or by L/C.
What's your delivery time?
Typically within 15 working days. For large quantities during busy periods, delivery may extend to approximately one month.
What's your price term?
Available terms include EXW (Poles Cost), FOB (Pole Cost + Land Transportation + Port Fees), CFR (FOB + Sea Freight), and CIF (CFR + Insurance).
