30FT Hot Dip Galvanized Octagonal Steel Pole with 500KG Min Break Load and 3mm Thickness
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-30 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 30FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355 | Thick: | 3.0mm |
| Load: | 500KGF | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | Distribution Power Line |
| Warranty: | 5 Years | ||
Product Description
These 9.15M/30FT steel poles are specifically designed for distribution lines applications. Manufactured by Yixing Hongxin Illumination Facilities Co., Ltd., a direct factory with over 25 years of experience, these poles combine advanced machinery with skilled engineering expertise to deliver superior quality hot dip galvanized electric steel poles.
Raw material conforms to general-purpose steel standard GB/T1591-2008, available in grades Q255, Q355, Q420, and Q460.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory utilizes advanced production equipment including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, and hydraulic straightener. This comprehensive machinery ensures the production of steel poles with optimal quality and precision.
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Our quality assurance process includes professional engineering oversight throughout manufacturing and pre-delivery inspections. Comprehensive testing includes:
- Lab Test
- Workload Test
- Steel thickness Test
- Galvanization thickness Test
We typically utilize 40HQ containers for shipping, with a port limit weight of 26 tons per container.
- EXW: Poles Cost
- FOB: Pole Cost + Land Transportation + Fee on Port
- CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
- CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
