Philippines NEA Standard Hot-dip Galvanized Octagonal Steel Pole with 500KG Min Break Load
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-35 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 35FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355 | Thick: | 3.0mm/2.75mm/2.9mm |
| Load: | 500KG | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | Distribution Power Line |
| Warranty: | 5 Years | ||
Product Description
High-quality 35FT steel poles manufactured to Philippines National Electrification Administration (NEA) standards. Features hot-dip galvanized octagonal design with 345MPa steel and 500KGS minimum break load capacity.
Yixing Hongxin Illumination Facilities Co., Ltd. is an industry and trade integrated factory specialized in manufacturing galvanized Philippines distribution steel poles with high quality, competitive pricing, and fast delivery (15 days).
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory owns advanced production lines and machines including:
- Two bending calibration machines
- Hydraulic plate shearing machine
- Cutting machine
- Slitting machine
- Two gas welding machines
- Hydraulic straightener
All equipment ensures production of steel poles with the best quality standards.
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
To ensure the highest quality, we have professional engineers to inspect the poles during manufacturing and before delivery.
Our comprehensive testing includes:
- Lab Test
- Workload Test
- Steel thickness Test
- Galvanization thickness Test
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
1. Are you a manufacturer or a trading company?
A: We are the direct factory manufacturer and the trading company.
2. Where is your company located?
A: Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
3. What are your main products?
A: Our main products are electric poles, street lighting poles, high mast pole, telecommunication tower poles, traffic signal poles, wind generation poles, etc.
4. What's your nearest port?
A: Shanghai Port is our nearest port.
5. What's your payment term?
A: Normally 30% deposit and rest by TT before shipping. Or L/C.
6. What's your delivery time?
A: Normally within 15 working days. If our factory is busy and your quantity is large, then around one month.
7. What's your price term?
A: Price Term: EXW, FOB, CFR or CIF.
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.
