60FT 18.288M Dodecagonal Galvanized Transmission Steel Power Pole with 1200KGF Design Load
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-60 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 60FT/18.288M | Shape: | Dodecagonal/ 12sides |
|---|---|---|---|
| Material: | Q345B | Thick: | 5mm |
| Load: | 1200KGF | Surface: | Hot Dip Galvanized / Black Tar Painting |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | Transmission Line |
| Warranty: | 5 Years | ||
Product Description
60FT transmission steel power poles manufactured with 345Mpa grade steel and hot-dip galvanized finish, designed for superior performance in power transmission applications.
- Steel material conforms to ASTM A572 Gr50, Q345B standards
- Welding complies with CSA and AWS D1.1 standards
- Hot-dip galvanized finish per ASTM A123 (minimum 86 microns zinc coating)
- Pole height: 60FT transmission pole
- Pole shape: Polygonal/Dodecagonal
- Surface treatment: Hot-dip galvanized with bituminous painting above and below grounding line
- Quality standard: ISO 9001 certified
- Easy installation and maintenance
- Packaging: Normally covered by sack or as per customer requirements
- Voltage rating: 69KV
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure the highest quality steel poles.
We manufacture transmission poles in various heights including 50FT, 55FT, 60FT, 65FT, 70FT, 75FT, 80FT, 85FT, and 90FT. All poles are custom manufactured according to customer specifications.
Professional engineers conduct thorough inspections during manufacturing and before delivery, including lab tests, workload tests, steel thickness tests, and galvanization thickness tests to ensure product quality.
We typically use 40HQ containers for shipping with a port limit weight of 26 tons per container.
FOB: Pole Cost + Land Transportation + Port Fees
CFR: Pole Cost + Land Transportation + Port Fees + Sea Freight
CIF: Pole Cost + Land Transportation + Port Fees + Sea Freight + Insurance
