30FT Height 500KGF Load Hot Dip Galvanized Octagonal Steel Distribution Pole
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-30 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 30FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355/Q235 | Thick: | 2.75mm/2.9mm/ 3.0mm |
| Load: | 500KGF | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | Distribution Power Line |
| Warranty: | 5 Years | ||
Product Description
The 30ft octagonal steel poles are widely used in distribution lines. With over 25 years of history, advanced machines, experienced engineers and skilled workers, Yixing Hongxin Illumination Facilities Co., Ltd. is the direct factory specialized in manufacturing hot dip galvanized electric steel poles.
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory owns advanced production lines and machines including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, etc. All ensure we produce steel poles with the best quality.
Steel Pole of National Electrification Administration (PHILIPPINES)
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
To ensure the quality, we have professional engineers to inspect the poles during manufacturing and before delivery. We conduct Lab Test, Workload Test, Steel thickness Test, Galvanization thickness Test, and more.
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
We are the direct factory manufacturer and the trading company.
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
Our main products are electric poles, street lighting poles, high mast pole, telecommunication tower poles, traffic signal poles, wind generation poles, etc.
Shanghai Port is our nearest port.
Normally 30% deposit and rest by TT before shipping. Or L/C.
Normally within 15 working days. If our factory is busy and your quantity is large, then around one month.
Price Term: EXW, FOB, CFR or CIF.
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.
