Compact 9m Urban Residential Distribution Steel Pole Noise-Dampened Eco-Friendly Surface Treatment Q235B
Product Details:
| Place of Origin: | Jiangsu, China |
| Brand Name: | ECER Steel Pole |
| Certification: | ISO 9001:2015, ISO 14001, RoHS |
| Model Number: | ESP-9M-URB-ECO |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 Pieces |
|---|---|
| Price: | USD 85-160 / Piece |
| Packaging Details: | Recyclable woven fabric wrap with biodegradable corrosion inhibitor, bundled on FSC-certified timber pallets |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T,L/C,PayPal |
| Supply Ability: | 7000 Pieces per Month |
|
Detail Information |
|||
| Material: | Q235B Eco-Steel (RoHS Compliant) | Height: | 9 Meters |
|---|---|---|---|
| Shape: | Round Tapered | Voltage Level: | 11kV / Low Voltage |
| Surface Treatment: | Hot-Dip Galvanized + Water-Based Acrylic Topcoat | Zinc Coating Thickness: | ≥65μm (458g/m²) |
| Acoustic Dampening: | Internal Elastomeric Damping Pad At Mid-span | Noise Reduction: | Up To 8dB(A) Reduction Vs Standard Pole |
| Top Diameter: | 130mm | Bottom Diameter: | 250mm |
| Wall Thickness: | 3-5mm | Color Options: | RAL 6009 Fir Green, RAL 7016 Anthracite, RAL 8019 Grey Brown |
| Highlight: | Compact 9m steel pole,Urban residential distribution pole,Noise-dampened eco-friendly steel pole |
||
Product Description
Compact 9m Urban Residential Distribution Steel Pole
Product Overview
The ESP-9M-URB-ECO is a community-conscious distribution pole engineered specifically for residential and suburban environments where aesthetics, noise, and environmental impact matter. At just 9 meters with a slim round tapered profile, this pole features internal elastomeric noise dampening that reduces wind-induced Aeolian vibration noise by up to 8dB(A), an eco-friendly water-based acrylic topcoat in nature-blending RAL colors, and fully RoHS-compliant Q235B steel construction.
Key Features
- Noise-Dampened Design: Factory-installed internal elastomeric damping pad at mid-span absorbs Aeolian vibration energy, converting it to negligible heat—eliminating the humming and buzzing that disturbs nearby residents
- Eco-Friendly Surface Treatment: HDG base layer topped with water-based acrylic coating (zero VOC emissions during application), free of heavy metal pigments, and fully compliant with EU RoHS Directive 2011/65/EU
- Nature-Blending Colors: Standard color palette (Fir Green, Anthracite Grey, Grey Brown) selected to minimize visual intrusion in treed and landscaped settings; custom RAL matching available for HOA and municipal requirements
- Compact 9m Profile: Shortest height in our distribution range, ideal for single-phase laterals and residential transformer mounting where tree canopies or planning restrictions limit pole height
- Sustainable Packaging: Recyclable woven fabric wrap, biodegradable VCI (Volatile Corrosion Inhibitor) film, and FSC-certified timber pallets reduce packaging waste by 60% versus conventional methods
Technical Specifications
| Parameter | Value |
| Pole Height | 9m (embedment 1.5m) |
| Voltage Class | 11kV / LV (415V) |
| Noise Reduction | ≤8 dB(A) at 5-15 m/s wind |
| Topcoat Type | Water-based acrylic, 60μm DFT |
| Environmental | RoHS compliant, zero VOC paint |
| Wind Rating | 130 km/h |
Applications
Specifically developed for residential subdivisions, gated communities, school and hospital campuses, parks and recreational areas, heritage districts with strict aesthetic controls, and any installation where community acceptance depends on minimizing visual and acoustic impact.
Community Acceptance Program
We provide complimentary 3D visual renderings of proposed pole installations superimposed on site photographs, community information brochures explaining noise-dampening technology, and sample color swatches for HOA/planning committee review. Our goal is to make steel pole adoption frictionless for community stakeholders.
