Multi-Functional 20m Telecom Power Composite Steel Pole Built-In Cable Management Modular Design Q345B
Product Details:
| Place of Origin: | Jiangsu, China |
| Brand Name: | ECER Steel Pole |
| Certification: | ISO 9001:2015, ISO 14001, CE |
| Model Number: | ESP-TPC-20M-MOD |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 Pieces |
|---|---|
| Price: | USD 650-1350 / Piece |
| Packaging Details: | Sectional transport with protective end caps, custom steel crating per section, VCI and desiccant packs included |
| Delivery Time: | 25-35 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1200 Pieces per Month |
|
Detail Information |
|||
| Material: | Q345B High-Strength Steel | Height: | 20 Meters |
|---|---|---|---|
| Shape: | Dodecagonal Tapered | Functions Integrated: | Power Distribution + Telecom + Street Light + CCTV |
| Cable Management: | Internal Segregated Conduits (3 Channels) | Surface Treatment: | Hot-Dip Galvanized + Weathering Steel Option |
| Zinc Coating Thickness: | ≥100μm (700g/m²) | Equipment Platforms: | 4 Modular Mounting Levels |
| Top Diameter: | 200mm | Bottom Diameter: | 580mm |
| Wall Thickness: | 5-12mm | Lightning Protection: | Integrated Down Conductor 50mm² Cu |
| Highlight: | 20m telecom steel pole,composite steel pole with cable management,modular Q345B electric pole |
||
Product Description
Multi-Functional 20m Telecom Power Composite Steel Pole
Product Overview
The ESP-TPC-20M-MOD redefines urban utility infrastructure by consolidating power distribution, telecommunications, street lighting, and surveillance functions into a single 20-meter composite steel pole. Featuring a built-in segregated cable management system with three independent internal conduits and 4 modular equipment mounting platforms, this Q345B steel pole eliminates the visual clutter of multiple separate poles while reducing total infrastructure cost by up to 40%.
Key Features
- Built-In Cable Management: Three segregated internal conduit channels (power, telecom, control) with accessible pull-boxes at each modular platform level, keeping all cabling protected and hidden from view
- Modular Equipment Platforms: 4 independently configurable mounting levels with standardized bolt patterns for antennas, RRUs, luminaires, CCTV cameras, and small cell equipment
- Smart City Ready: Factory-integrated 50mm² copper lightning down conductor,预留 sensor mounting brackets, and internal cable pathways for IoT devices and environmental sensors
- Q345B Structural Core: High-strength steel backbone designed for cumulative equipment loads up to 500kg plus wind loading per ASCE 7-16
- Dual-Finish Options: Standard HDG + powder coat or weathering steel (Corten equivalent) for architectural landmark projects requiring a natural rust-patina aesthetic
Technical Specifications
| Parameter | Value |
| Total Height | 20m (above ground 17.5m) |
| Platform Levels | 4 (at 8m, 12m, 16m, 20m) |
| Internal Conduits | 3 channels: Ø50mm (power), Ø40mm (telecom), Ø25mm (control) |
| Equipment Load | 500kg max distributed |
| Access Door | Lockable 600x400mm at base level |
| Wind Rating | 180 km/h (loaded condition) |
Applications
Purpose-designed for smart city deployments, 5G small cell densification corridors, intelligent transportation systems (ITS) highways, urban beautification projects, and campus-scale utility consolidation. Single pole replaces 3-4 separate structures, dramatically reducing streetscape congestion.
Smart City Integration
Pre-engineered mounting interfaces for: 5G AAU/BBU equipment (Nokia, Ericsson, Huawei compatible), traffic monitoring cameras (Axis, Hikvision), environmental sensors (PM2.5, noise, temperature), Wi-Fi 6 access points, digital signage displays, and EV charging integration at base level. Custom platform configurations designed to your specific equipment schedule.
