25FT Q355B 2.75mm Direct Buried Galvanized Octagonal Steel Pole with 500KGF Min Break Load for Power Distribution
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-2527 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 25FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355B | Thick: | 2.75mm |
| Load: | 500KGF | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Coating Over 86 Microns | Applied: | 15kv Distribution Power Line |
| Warranty: | 5 Years | ||
Product Description
The Hot Dip Galvanized NEA Standard Octagonal 25FT Steel Poles are widely used in the Philippines 15KV distribution power lines. With over 25 years history, advanced machines, experienced engineers and skilled workers, Yixing Hongxin Illumination Facilities Co., Ltd. is the direct factory specialized in manufacturing these 25ft steel poles.
Height: 25FT
Material: Q355B/ ASTM A36
Thickness: 2.75mm
Shape: Octagonal/ 8 sides
Design Load: 500KGF
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400,S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory owns advanced production lines and machines including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, etc. All insure us to produce steel poles with best quality.
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT.
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
To ensure the quality, we have professional engineers to inspect the poles during the manufacturing and before delivery.
We have Lab Test, Workload Test, Steel thickness Test, Galvanization thickness Test, etc.
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.
