50FT-100FT Hot Dip Galvanized Polygonal Steel Utility Pole for Power Distribution
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-50100 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 50FT-100FT | Shape: | Polygonal |
|---|---|---|---|
| Material: | Q355B/ ASTM A36/ Q460/ ASTM A572 GR65 | Thick: | 5.0mm-10.0mm |
| Surface: | Hot Dip Galvanized | Galvanizing Thick: | Min Average Coating Over 86 Microns |
| Applied: | Distribution/Transmission Power Line | Warranty: | 5 Years |
Product Description
The Hot Dip Galvanized Buried Steel Poles are widely used in the distribution and transmission power lines. With over 25 years history, advanced machines, experienced engineers and skilled workers, Yixing Hongxin Illumination Facilities Co.,Ltd. is the direct factory specialized in manufacturing these steel poles.
- Height: 50FT-100FT
- Material: Q355B/ ASTM A36/ Q460/ ASTM A572 GR65
- Thickness: 5.0mm-10.0mm
- Shape: Polygonal
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400,S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory owns advanced production lines and machines including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, etc. All insure us to produce steel poles with best quality.
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
To ensure the quality, we have professional engineers to inspect the poles during the manufacturing and before delivery.
We have Lab Test, Workload Test, Steel thickness Test, Galvanization thickness Test, etc.
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
