90FT Height Dodecagonal Transmission Steel Pole with 2000KGF Min Break Load for Power Transmission
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-902 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 90FT | Shape: | Dodecagonal |
|---|---|---|---|
| Material: | Q460 | Thick: | 5mm |
| Load: | 2000KGF | Surface: | Hot Dip Galvanized+Bitumen Painting |
| Galvanizing Thick: | Min Average Over 100 Microns | Applied: | Power Transmission Line |
| Warranty: | 5 Years | ||
| Highlight: | 90FT transmission steel pole,dodecagonal power transmission pole,2000KGF break load steel pole |
||
Product Description
Yixing Hongxin Illumination Facilities Co., Ltd. is the Chinese factory specialized in producing 90FT transmission steel poles and sub-transmission steel poles.
Besides these NEA standard poles, our factory also produces 50FT-120FT Transmission poles, Steel Lighting Poles, Traffic Signal Poles, Substation Structures, Steel Crossarm, Steel Towers and other steel components.
Our factory has professional engineers to design practical poles and save costs for our clients. To design practical poles for customer use, we typically require the following parameters:
- Pole top design load
- Position of the load (distance from the top)
- Wind speed
- Wire distribution configuration
- Pole type (Burial Type or Base Plate type)
- Connection mode (slip joint or flange)
- Other parameters for further discussion
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory owns advanced production lines and machines including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, etc. All equipment ensures we produce steel poles with the best quality.
To ensure quality, we have professional engineers to inspect poles during manufacturing and before delivery.
We conduct Lab Tests, Workload Tests, Steel Thickness Tests, Galvanization Thickness Tests, and more.
We offer different packing options to meet your requirements:
- No packing - bare poles delivered directly (most economical)
- Sack wrap
- Non-woven fabrics wrap
We normally use 40ft containers with a port limit weight of 26 tons. For poles with flanges or to avoid scratches during delivery, we use 40ft open top containers (slightly more costly than standard containers).
We typically use 40HQ containers with a port limit weight of 26 tons.
Price Terms: EXW, FOB, CFR or CIF.
- EXW: Poles Cost
- FOB: Pole Cost + Land Transportation + Fee on Port
- CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
- CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
