90FT Q460 Dodecagonal Galvanized Transmission Steel Pole with 11000KGF Min Break Load
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-90 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 90FT | Shape: | Dodecagonal/ 12sides |
|---|---|---|---|
| Material: | Q460 | Thick: | 8mm |
| Load: | 11000KGF | Surface: | Hot Dip Galvanized / Black Tar Painting |
| Galvanizing Thick: | Min Average Over 100 Microns | Applied: | Transmission Line |
| Warranty: | 5 Years | ||
| Highlight: | 90FT galvanized transmission steel pole,Dodecagonal transmission pole 11000KGF load,Q460 steel transmission pole with warranty |
||
Product Description
High-quality 90FT transmission steel poles manufactured with Q460 grade steel and hot-dip galvanized finish, designed for superior performance in power transmission applications.
- Steel material conforms to ASTM A572 Gr65, Q460 standards
- Welding complies with CSA and AWS D1.1 standards
- Hot-dip galvanized finish per ASTM A123 (minimum 100 microns zinc coating)
- Pole height: 90FT transmission pole
- Pole shape: Polygonal/Dodecagonal
- Surface treatment: Hot-dip galvanized with bituminous painting above and below grounding line
- Quality standard: ISO 9001 certified
- Easy installation and maintenance
- Packaging: Normally covered by sack or as per customer requirements
- Voltage rating: 69KV
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure the highest quality steel poles.
We manufacture transmission poles in various heights including 50FT, 55FT, 60FT, 65FT, 70FT, 75FT, 80FT, 85FT, and 90FT. All poles are custom manufactured according to customer specifications.
Professional engineers conduct thorough inspections during manufacturing and before delivery, including lab tests, workload tests, steel thickness tests, and galvanization thickness tests to ensure product quality.
We typically use 40HQ containers for shipping with a port limit weight of 26 tons per container.
FOB: Pole Cost + Land Transportation + Port Fees
CFR: Pole Cost + Land Transportation + Port Fees + Sea Freight
CIF: Pole Cost + Land Transportation + Port Fees + Sea Freight + Insurance
