40FT 12.192M 1 Segment 500KG Load Hot Dip Galvanized Octagonal Distribution Steel Pole
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-40 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 40FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355/Q235 | Thick: | 2.75mm/ 2.9mm/ 3.0mm |
| Load: | 500KG | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | Distribution Power Line |
| Warranty: | 5 Years | ||
Product Description
40FT 12.192M 1 Segment 500KG Load Hot Dip Galvanized Octagonal Distribution Steel Pole
Material Specifications
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory operates advanced production lines and machinery including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, and more. This equipment ensures we produce steel poles of the highest quality.
Product Specifications
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
To ensure product quality, our professional engineers conduct inspections throughout the manufacturing process and before delivery. Our testing procedures include:
- Lab Test
- Workload Test
- Steel Thickness Test
- Galvanization Thickness Test
Delivery Information
We typically use 40HQ containers for shipping, with a port limit weight of 26 tons per container.
Frequently Asked Questions
1. Are you a manufacturer or a trading company?
We are both a direct factory manufacturer and a trading company.
2. Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China (mainland).
3. What are your main products?
Our main products include electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
4. What's your nearest port?
Shanghai Port is our nearest port.
5. What's your payment term?
Normally 30% deposit with the remainder by TT before shipping, or L/C.
6. What's your delivery time?
Normally within 15 working days. For large quantities during busy periods, delivery may take approximately one month.
7. What's your price term?
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
