25FT Height 500KGF Load 86 Microns Coating Hot-dip Galvanized Octagonal Electric Steel Pole for Power Distribution
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-25 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 25FT | Top Diameter: | 120mm |
|---|---|---|---|
| Material: | Q355B | Thick: | 3.0mm |
| Shape: | Octagonal | Load: | 500KGF |
| Welding: | AWS D1.1 | Surface: | Hot Dip Galvanized ASTM A123 |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | 15KV Power Line |
| Warranty: | 5 Years | ||
| Highlight: | 25FT Height Electric Steel Pole,500KGF Load Galvanized Steel Pole,86 Microns Coating Power Distribution Pole |
||
Product Description
25FT 3mm Thick 500KGF Q355B Hot-dip Galvanized Octagonal Steel Poles
High-quality octagonal steel poles featuring 25FT height, 3mm thickness, 500KGF design load capacity, Q355B steel grade, and hot-dip galvanized coating with minimum 86 microns average thickness for superior corrosion resistance.
Manufacturer Profile
YIXING HONGXIN ILLUMINATION FACILITIES CO., LTD. is a professional steel pole manufacturer established in 2001 with 30 million RMB registered capital. Located in Yixing City, Jiangsu, China, our 15,000 square meter facility employs 50 staff and produces over 1000 tons of steel poles monthly.
Our comprehensive product range includes power transmission poles, wind power generation poles, railway electrification poles, high-mast lighting poles, street lighting poles, traffic signal poles, communication towers, and flag poles.
Product Specifications
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Material Specifications
| China GB Standard | American ASTM Equivalent | International Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our advanced manufacturing facility includes bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding equipment, and hydraulic straighteners to ensure precision and quality in every steel pole produced.
Quality Control
Professional engineers conduct comprehensive inspections throughout the manufacturing process and before delivery. Our quality assurance includes lab testing, workload testing, steel thickness verification, and galvanization thickness measurement.
Packaging & Delivery Options
- Bare poles delivery - most economical option
- Sack wrap packaging
- Non-woven fabrics wrap
We typically use 40HQ containers with a port limit weight of 26 tons. For poles with flanges or to prevent scratches during transit, we recommend 40ft open-top containers.
Frequently Asked Questions
Are you a manufacturer or trading company?
We are a direct factory manufacturer with trading capabilities.
Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China.
What are your main products?
Electric poles, street lighting poles, high mast poles, telecommunication towers, traffic signal poles, and wind generation poles.
What's your nearest port?
Shanghai Port is our nearest shipping port.
What's your payment term?
30% deposit with balance by TT before shipping, or Letter of Credit.
What's your delivery time?
Typically within 15 working days, extended to approximately one month for large quantities during busy periods.
What's your price term?
EXW, FOB, CFR, or CIF pricing options available.
