30FT/35FT Hot-dip Galvanized Electric Steel Pole with 500KGS Load for Power Distribution
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-3035 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 30FT/35FT | Material: | Q355B |
|---|---|---|---|
| Thick: | 2.75mm/ 3.0mm | Load: | 500KGF |
| Surface: | Hot Dip Galvanized | Galvanizing Thick: | Min Average Over 86 Microns |
| Shape: | Octagonal/ 8 Sides | Applied: | 15kv Distribution Power Line |
| Warranty: | 5 Years | ||
| Highlight: | 30FT/35FT Electric Steel Pole,500KGS Load Galvanized Steel Pole,Hot-dip Galvanized Power Distribution Pole |
||
Product Description
30FT/35FT Q355B 500KGS Load Philippines NEA Standard Steel Poles
Professional-grade hot-dip galvanized octagonal buried electric steel poles designed to meet Philippines National Electrification Administration standards. These poles feature Q355B material with minimum yield strength of 345MPa and 500kg load capacity.
Product Specifications
Pole Height: 30FT/35FT
Type: Direct Buried Type
Segment: 1 Segment
Shape: Octagonal
Material: ASTM A572 GR50/Q355B with min yield strength 345MPa
Type: Direct Buried Type
Segment: 1 Segment
Shape: Octagonal
Material: ASTM A572 GR50/Q355B with min yield strength 345MPa
Manufacturer Profile
Yixing Hongxin Illumination Facilities Co., Ltd - Integrated factory and trading company with over 25 years of experience in manufacturing hot-dip galvanized steel poles. Exporting to Southeast Asia, Africa, Europe, Australia, the Middle East, and South America.
Material Specifications
Raw material conforms to GB/T1591-2008 standard using Q255, Q355, Q420, Q460 steel grades.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure superior quality steel poles.
Product Specifications Table
Philippines NEA Standard Distribution Steel Poles - 25FT to 45FT
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPa) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
Professional engineers conduct comprehensive inspections throughout the manufacturing process and before delivery. Testing includes Lab Tests, Workload Tests, Steel Thickness Tests, and Galvanization Thickness Tests to ensure product quality.
Delivery Information
Standard delivery via 40HQ containers with port limit weight of 26 tons per container.
Frequently Asked Questions
1. Are you a manufacturer or a trading company?
We are the direct factory manufacturer and the trading company.
2. Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
3. What are your main products?
Our main products are electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
4. What's your nearest port?
Shanghai Port is our nearest port.
5. What's your payment term?
Normally 30% deposit and rest by TT before shipping, or L/C.
6. What's your delivery time?
Normally within 15 working days. For large quantities during busy periods, approximately one month.
7. What's your price term?
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
