70FT Dodecagonal Hot Dip Galvanized Steel Transmission Pole for Power Transmission Lines
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-70 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 70FT | Shape: | Dodecagonal |
|---|---|---|---|
| Material: | Q355 | Thick: | 5.0mm |
| Surface: | Hot Dip Galvanized | Galvanizing Thick: | Min Average Over 86 Microns |
| Applied: | Power Transmission Line | Warranty: | 5 Years |
| Highlight: | 70FT Steel Transmission Pole,Dodecagonal Galvanized Steel Pole,Hot Dip Galvanized Power Transmission Pole |
||
Product Description
Philippines 5mm Q460 1200KGF Hot Dip Galvanized Dodecagonal Buried 70FT Steel Transmission Poles
High-quality steel transmission poles designed for the Philippines market, featuring 5mm thickness, Q460 steel grade, 1200KGF design load, hot dip galvanized coating, and dodecagonal cross-section.
Material Specifications
Raw material conforms to GB/T1591-2008 standards with various steel grades available:
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure superior quality steel poles.
Available Products
Transmission poles available in various heights: 50FT, 55FT, 60FT, 65FT, 70FT, 75FT, 80FT, 85FT, 90FT. All specifications are customizable according to customer requirements.
Philippines National Electrification Administration Specifications
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
Professional engineers conduct comprehensive inspections throughout the manufacturing process and before delivery. Testing includes laboratory analysis, workload testing, steel thickness verification, and galvanization thickness measurement.
Delivery Information
Standard delivery uses 40HQ containers with a maximum weight capacity of 26 tons per container.
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are both the direct factory manufacturer and a trading company.
Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
What are your main products?
Our main products include electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
What's your nearest port?
Shanghai Port is our nearest port.
What's your payment term?
Standard terms: 30% deposit with balance by TT before shipping, or Letter of Credit.
What's your delivery time?
Typically within 15 working days. For large quantities during busy periods, delivery may extend to approximately one month.
What's your price term?
Available terms: EXW, FOB, CFR, or CIF. EXW covers pole cost only; FOB includes land transportation and port fees; CFR adds sea freight; CIF includes all costs plus insurance.
