60FT 12-Sides 1200KGF Hot-dip Galvanized Transmission Steel Pole with Bitumen Painting
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-60 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 60FT | Shape: | Dodecagonal |
|---|---|---|---|
| Material: | Q355B | Thick: | 5mm |
| Load: | 1200KGF | Surface: | Hot Dip Galvanized |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | Power Transmission Line |
| Warranty: | 5 Years | ||
| Highlight: | 60FT Transmission Steel Pole,12-Sides Galvanized Steel Pole,1200KGF Power Transmission Pole |
||
Product Description
60FT 12-Sides Q355B 1200KGF Hot-dip Galvanized Buried Transmission Steel Poles with Bitumen Painting
Yixing Hongxin Illumination Facilities Co., Ltd. specializes in manufacturing 60FT transmission steel poles and sub-transmission steel poles.
Product Range
In addition to NEA standard poles, our factory produces:
- 50FT-120FT Transmission Poles
- Steel Lighting Poles
- Traffic Signal Poles
- Substation Structures
- Steel Crossarms
- Steel Towers
- Other steel components
Our professional engineering team designs practical, cost-effective poles. To create custom designs, we typically require the following parameters:
- Pole top design load
- Load position (distance from top)
- Wind speed requirements
- Wire distribution configuration
- Pole type (Burial Type or Base Plate type)
- Connection mode (slip joint or flange)
- Additional specifications as needed
Material Specifications
Raw materials comply with GB/T1591-2008 standards:
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our advanced production facility includes:
- Two bending calibration machines
- Hydraulic plate shearing machine
- Cutting machine
- Slitting machine
- Two gas welding machines
- Hydraulic straightener
This comprehensive equipment ensures the highest quality steel pole production.
Quality Inspection
Our quality assurance process includes comprehensive testing by professional engineers throughout manufacturing and before delivery:
- Lab Testing
- Workload Testing
- Steel Thickness Testing
- Galvanization Thickness Testing
Packing and Delivery Options
We offer flexible packing solutions:
- No packing - bare poles delivered directly (most economical)
- Sack wrap packaging
- Non-woven fabrics wrap
Shipping specifications:
- Standard 40ft container usage
- Port limit weight: 26 tons per 40ft container
- 40ft open top containers available for flanged poles or scratch prevention
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are both a direct factory manufacturer and a trading company.
Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China.
What are your main products?
Electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, wind generation poles, and related structures.
What's your nearest port?
Shanghai Port is our nearest port.
What's your payment term?
Standard terms: 30% deposit with balance by TT before shipping, or L/C.
What's your delivery time?
Typically within 15 working days. For large quantities during busy periods, approximately one month.
What's your price term?
Available terms: EXW, FOB, CFR, or CIF.
