70FT Dodecagonal Hot Dip Galvanized Transmission Steel Pole with Bitumen Painting and Sack Wrap
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-70 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 70FT | Shape: | Dodecagonal/ 12sides |
|---|---|---|---|
| Material: | Q355 | Thick: | 5.0mm |
| Surface: | Hot Dip Galvanized / Bitumen Painting | Galvanizing Thick: | Min Average Over 86 Microns |
| Applied: | Power Transmission Line | Warranty: | 5 Years |
| Highlight: | 70FT Transmission Steel Pole,Dodecagonal Galvanized Steel Pole,Hot Dip Galvanized Power Transmission Pole |
||
Product Description
1200KGF Dodecagonal Hot Dip Galvanized 70FT Transmission Steel Pole
This heavy-duty transmission steel pole features a dodecagonal (12-sided) design with hot dip galvanized coating, bitumen painting, and sack wrap protection. Engineered for superior performance in transmission line applications.
For more details or inquiries, please contact Lisa via email:
873819938@qq.com
Material Specifications
Raw materials comply with GB/T1591-2008 standards using Q255, Q355, Q420, and Q460 steel grades.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure the highest quality steel poles.
Available Products
We manufacture transmission poles in various heights: 50FT, 55FT, 60FT, 65FT, 70FT, 75FT, 80FT, 85FT, and 90FT. All specifications are customizable according to customer requirements.
Philippines National Electrification Administration Specifications
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
Professional engineers conduct comprehensive inspections throughout the manufacturing process and before delivery. Our quality control includes Lab Testing, Workload Testing, Steel Thickness Testing, and Galvanization Thickness Testing.
Delivery Information
We typically use 40HQ containers for shipping with a maximum weight limit of 26 tons per container.
Frequently Asked Questions
Are you a manufacturer or a trading company?
We operate as both a direct factory manufacturer and a trading company.
Where is your company located?
Our factory is located at Yinhe Road No.3, Wanshi town, Jiangsu, China.
What are your main products?
Our main products include electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
What's your nearest port?
Shanghai Port is our nearest shipping port.
What's your payment term?
Standard payment terms: 30% deposit with balance paid by TT before shipping, or Letter of Credit (L/C).
What's your delivery time?
Typically within 15 working days. For large quantities during busy periods, delivery may extend to approximately one month.
What's your price term?
Available price terms:
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Port Fees
CFR: Pole Cost + Land Transportation + Port Fees + Sea Freight
CIF: Pole Cost + Land Transportation + Port Fees + Sea Freight + Insurance
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Port Fees
CFR: Pole Cost + Land Transportation + Port Fees + Sea Freight
CIF: Pole Cost + Land Transportation + Port Fees + Sea Freight + Insurance
