Philippines NEA Standard 25FT-45FT Hot Dip Galvanized Octagonal Steel Pole for 15KV Power Lines
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-2545 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 25FT-45FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355B | Thick: | 2.5mm/ 3.0mm/4.0mm |
| Load: | 300KGF/500KGF/750KGF | Surface: | Hot Dip Galvanized / Black Tar Painting |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | 15kv Power Line |
| Warranty: | 5 Years | ||
| Highlight: | Hot Dip Galvanized Distribution Steel Pole,25FT-45FT Octagonal Steel Pole,NEA Standard Electric Steel Pole |
||
Product Description
Philippines NEA Standard 25FT-45FT Hot Dip Galvanized Octagonal Steel Pole
NEA Standard steel poles are widely used in the Philippines 15KV power lines. With over 25 years of experience, advanced machinery, and skilled workforce, Yixing Hongxin Illumination Facilities Co., Ltd. specializes in manufacturing hot dip galvanized electric steel poles.
Product Specifications
Height: 25FT-45FT
Material: Q355B/ASTM A36
Thickness: 2.5mm/3.0mm/4.0mm
Shape: Octagonal/8 sides
Design Load: 300KGF/500KGF/750KGF
Material: Q355B/ASTM A36
Thickness: 2.5mm/3.0mm/4.0mm
Shape: Octagonal/8 sides
Design Load: 300KGF/500KGF/750KGF
Material Specifications
Raw materials comply with GB/T1591-2008 standards using Q255, Q355, Q420, Q460 steel grades.
| China-GB | America-ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure the highest quality steel poles.
Finished Product Specifications
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
Professional engineers conduct comprehensive inspections throughout manufacturing and before delivery. Our quality control includes Lab Testing, Workload Testing, Steel Thickness Testing, and Galvanization Thickness Testing.
Delivery Information
We typically use 40HQ containers for shipping. The port weight limit for a 40HQ container is 26 tons.
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are the direct factory manufacturer and also operate as a trading company.
Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
What are your main products?
Our main products are electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
What's your nearest port?
Shanghai Port is our nearest port.
What's your payment term?
Normally 30% deposit and the remainder by TT before shipping, or by L/C.
What's your delivery time?
Normally within 15 working days. For large quantities during busy periods, delivery may take approximately one month.
What's your price term?
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Port Fees
CFR: Pole Cost + Land Transportation + Port Fees + Sea Freight
CIF: Pole Cost + Land Transportation + Port Fees + Sea Freight + Insurance
FOB: Pole Cost + Land Transportation + Port Fees
CFR: Pole Cost + Land Transportation + Port Fees + Sea Freight
CIF: Pole Cost + Land Transportation + Port Fees + Sea Freight + Insurance
