25FT/40FT Height Hot Dip Galvanized Q355 Electric Steel Pole for Power Distribution
Product Details:
| Place of Origin: | China |
| Brand Name: | Hongxin |
| Certification: | ISO 9001 |
| Model Number: | HX-2540 |
| Document: | Company Profile-HX.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | 800 USD |
| Packaging Details: | Bare delivery, Sack Wrap or Fabrics |
| Delivery Time: | Within 15 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Height: | 25FT/40FT | Shape: | Octagonal/ 8 Sides |
|---|---|---|---|
| Material: | Q355 | Thick: | 2.5mm/ 3.0mm |
| Load: | 300KGF/500KGF | Surface: | Hot Dip Galvanized / Black Tar Painting |
| Galvanizing Thick: | Min Average Over 86 Microns | Applied: | 15kv Power Line |
| Warranty: | 5 Years | ||
| Highlight: | 25FT/40FT Height Electric Steel Pole,Hot Dip Galvanized Galvanized Steel Utility Pole,Q355 Material Power Distribution Pole |
||
Product Description
NEA Standard 25FT & 40FT Power Distribution Steel Poles
Galvanized steel utility poles manufactured to Philippines National Electrification Administration standards.
Product Specifications
Height: 25FT / 40FT
Design Load: 300kgf / 500KGF
Material: Q355B / ASTM A572 Gr50 with minimum yield strength 355MPa
Shape: Octagonal
Thickness: 2.5mm / 3.0mm
Manufacturing Capabilities
- China Steel Pole Factory with over 25 years of experience
- Advanced production machinery and equipment
- Experienced engineering team
- Skilled production workforce
Material Standards
Raw materials conform to GB/T1591-2008 standards using Q255, Q355, Q420, Q460 steel grades.
| China GB | America ASTM | Equivalent |
|---|---|---|
| Q255 | Grade D | SS400, S235JO |
| Q355 | Grade50[345] | S355JR |
| Q420 | Grade60[415] | S420NL |
| Q460 | Grade65[450] | S460NL |
Manufacturing Process
Our factory utilizes advanced production lines including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure the highest quality steel poles.
Finished Product Specifications
NEA Standard Distribution Steel Poles for Philippines market
| Height (ft) | Thickness (mm) | Butt Diameter (mm) | Top Diameter (mm) | Design Load (kg) | Yield Stress (MPa) | Zinc Coating (microns) |
|---|---|---|---|---|---|---|
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 4.0 | 328 | 127 | 750 | 345 | 86 |
Quality Inspection
Professional engineers conduct comprehensive inspections throughout manufacturing and before delivery, including lab tests, workload tests, steel thickness tests, and galvanization thickness tests.
Delivery Information
Standard shipping via 40HQ containers with port limit weight of 26 tons.
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are both the direct factory manufacturer and a trading company.
Where is your company located?
Our factory is located at Yinhe Road No.3, Wanshi town, Jiangsu, China.
What are your main products?
Electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
What's your nearest port?
Shanghai Port is our nearest port.
What's your payment term?
Normally 30% deposit with balance by TT before shipping, or L/C.
What's your delivery time?
Typically within 15 working days, or approximately one month for large quantities during busy periods.
What's your price term?
EXW: Poles Cost; FOB: Pole Cost + Land Transportation + Port Fees; CFR: FOB + Sea Freight; CIF: CFR + Insurance.
