Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M

Certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
I'm Online Chat Now

Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M

Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M
Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M

Large Image :  Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M

Product Details:
Place of Origin: China
Brand Name: JSBS
Certification: ISO9001:2008
Model Number: BS/RL - 17
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Use sack package the poles or straw or wood or steel strap, etc
Delivery Time: 15 - 25 work days
Payment Terms: D/P, Western Union, L/C, T/T
Supply Ability: 2000 Ton per month
Detailed Product Description
Height: 8M , 10M Finishing: Hot Dip Galvanized
Shape: Conical , Round , Octagonal Thickness: 3.0mm - 8.0mm
Applicant: Street, Road, Parking Lot, Square Material: Steel
Min Yield Stress: 235 Mpa Tolerance: +-2%
Highlight:

parking lot lighting poles

,

Square Light post

Q345 Steel Lighting Pole 8M 10M Lamp Post , Parking Lot Light Pole With Colorful Painting

Specification





Height 8M ,10M
Application Road ,Street, Highway, etc
Shape Conical , polygonal , Round
Lamp Power

20 W- 400 W (HPS/MH)

220V (+-10%) /50Hz

Arm Single or Double
Lighting Fixture IP 65
Working Atmosphere of Lighting Fixture -35 °C~+45 °C
Surface Treatment Hot dip galvanized with ASTM A 123
Safety Against earthquake of 8 grade
Wind Speed 160 Km/Hour
Min Yield Strength 355 mpa
Min Ultimate Tensile Strength 490 mpa
Max ultimate tensile strength 620 mpa
Standard ISO 9001 : 2008
Thickness 2.5 mm to 30 mm
Material Steel Q235, Q345, SS400, S355JR,etc
Powder Coated Color as request






Description


Our street lighting poles are non-standard and have various types for you to choose. The pole price is based on pole specification which meaning different specification with different price. So better advise us your request specification so that we can quote you the exact price. Of course we can recommend you and give you some advice if you are a new buyer.


See following the parameter for customers reference:



1. We can supply the product based on client's required drawing ,but also can supply the design for any kinds of
   Lighting Poles for customers to select.

2. Matercial : hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3

3. Deal: Hot dip galvanized Following ASTM A 123 or any other stardand by client required.

4. Packing: Plastic bulble , Mat & Straw Bale or following client required

5. Arm : Single or Double Arms

6. Thickness: from 3.0 mm to 8.0 mm

7. Shape: polygonal ( 6-side,8side,12-side,16side) round tapered , Conical

8. Easy install and maintenance.



The Advantages of the Parking Lot Light Pole :

  • Short Construction Cycle
  • Low Overall Cost
  • Easy Installation and Maintenance
  • Weather Resistance
  • Anti-corrosion

Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M 0

Quality Control Management
Our company processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.
Meanwhile, it has formed a scientific and strict quality mangement system, which effectively and strictly guarantees the quality control of products form raw material to finished products.
The rate of pass of street linght pole is 98%. Smooth installation and complete match. The rate of customer satisfaction is 95%,

Our Services

1. Reply your inquiry in 24 working hours.

2. Experienced staffs answer all your questions in fluent English.

3. Customized design is available. UEM & UBM are welcomed.

4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers     and staff.

5. Special discount and protection of sales are provided to our distributor.

6. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles
    for more than 10 years, competitive with good quantity.

7 Sample: We can send out sample for test in one week if the order quantity is big enough.
   But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal
   order.

8. As an honest seller, we always use superior raw material, advanced machines,
   skilled technicians to ensure our products to be finished in high quality and stable feature.

Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M 1


We own advance production line, machine including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All the purpose is to satisfied our customers.

Production Process


- Material preparation
- Bending
- Welding
- Repair and grinding
- Reforming
- Flushing
- Fix bottom plate
- Welding bottom plate
- Opening door
- Welding door strip, electric strip, and locking
- Bending arm
- Hot dip galvanization
- Plastic powder painted
- Inspection
- Delivery




Through the efforts of the company staff, the support and cooperation from all over the world. The company's products have been exported to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World in average every day.




Q345 Steel Material parking lot light post , Colorful Painting metal light pole 8M / 10M 2


Terms and Conditions


1. Price Term: EXW, FOB, CFR or CIF.

Ø EXW: Poles Cost
Ø FOB : Pole Cost + Land Transportation + Fee on Port
Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight
Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.

2. MOQ: One 40FT Container.


3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other
   payment way can be negotiated.


4. Delivery Time: 15 working days per container after PI / drawing / prepayment confirmed.


5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom,or according to clients’
    requirement.
