Q345 Steel Material Octagonal Electric Metal Utility Pole for Train Station

Certification
Good quality Electrical Power Pole for sales
Good quality Electrical Power Pole for sales
I'm Online Chat Now

Q345 Steel Material Octagonal Electric Metal Utility Pole for Train Station

China Q345 Steel Material Octagonal Electric Metal Utility Pole for Train Station supplier

Large Image :  Q345 Steel Material Octagonal Electric Metal Utility Pole for Train Station

Product Details:

Place of Origin: China
Brand Name: BOSHENG
Certification: ISO9001:2008
Model Number: BS/HS - 03

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Pack the poles with sack or straw or wood or steel strap, etc
Delivery Time: 15 - 25 work days
Payment Terms: D/P, L/C, T/T, Western Union
Supply Ability: 2000 Ton per month
Contact Now
Detailed Product Description
Material: Steel Min Yield Stress: 345 Mpa
Shape: Round , Octagonal Warrantly: 20 Years
Finishing: Hot Dip Galvanized Galvanized: ASTM A123
Welding: Longitudinal Tolerance: +-2%



Q345 Round / Octagonal Galvanized Electric Metal Utility Pole for Train Station Use



Specification


Products Q345 Round / Octagonal Galvanized Electric Metal Utility Pole for Train Station Use
Shape Conical / Round
Material Hot Roll Steel Q345( Gr50 ), Q420 ( Gr60 ), Q460 ( Gr65 )
Wall thickness 3mm~20mm
Section One
Welding

· Welding complies with AWS D1.1 standard.

· CO2 welding or submerged arc auto methods

· No fissure, scar, overlap, layer or other defect

Zinc Coating ≥ 86 Microns on average
Base plate Base plate is square/round/Polygon with slotted holes for anchor bolt
Certificate ISO9001:2008 , AAA Credit , CM, etc








Description




Our steel poles, being manufactured from steel sheet that has been subjected to hydraulic pressure and longitudinal welding, has a tapered tubular structure with a multilateral cross-section. To achieve a proper height, steel poles can be assembled by insert mode or flange mode at the installation site.




The hot-dip galvanization technique could protect steel pole from corrosion for as long as 50 years


As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole could be utilized to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.





Production Process



  • Raw material test
  • Cutting
  • Bending
  • Welding (longitudinal )
  • Dimension verify
  • Flange welding
  • Hole drilling
  • Calibration
  • Deburr
  • Galvanization or powder coating or Bituminous painting
  • Recalibration
  • Packages

Q345 Steel Material Octagonal Electric Metal Utility Pole for Train Station



Galvanization.



Our factory own 3 galvanization plants to ensure the good quality. Hot dip galvanized in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123. Zinc Coating thick min 86 microns.





Features:



1. We can supply the product based on client's required drawing, but also can supply the design for any kinds of

    electric poles for customers to select.



2. Matercial : hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3



3. Deal: Hot dip galvanized Following ASTM A 123 or any other stardand by client required.



4. Packing: Plastic bulble , Mat &Straw Bale or following client required



5. Length : within 14meters once forming( single section)



6. Thickness: from 2.5mm to 22mm



7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.



8. Easy install and maintenance.



Q345 Steel Material Octagonal Electric Metal Utility Pole for Train Station



FAQ



How is the quality of your products?


Our products are manufactured strictly according to national and international standard, and we take a test on every pole before delivered.


Guaranteed:


If products' quality doesn’t accord to description as we give or the promise before you place order, we promise 100% refund.


How about price?


we are the factory and are able to give you the lowest price below market one, and discount can be given based on quantity”.



Why choose us?



Good Quality; Low Price. best Service !



Q345 Steel Material Octagonal Electric Metal Utility Pole for Train Station



Through the efforts of the company staff, the support and cooperation from all over the world. The company's products have been exported to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World in average every day.
