69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole

Certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
I'm Online Chat Now

69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole

69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole
69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole

Large Image :  69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole

Product Details:
Place of Origin: China
Brand Name: JSBS
Certification: ISO9001:2008
Model Number: BS/PT - 26
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Use sack to pack the poles or as customers' requests.
Delivery Time: 15 - 25 work days
Payment Terms: D/P, L/C, T/T, Western Union
Supply Ability: 2500 Ton per month
Detailed Product Description
Height: 70FT Material: Steel Q345 Q420 Q460
Type: Burial Zinc Coating: Hot Dip Galvanized
Galvanized: Min 86μm Shape: Dodecagonal
Finishing: Hot Dip Galvanized Tolerance: ±2%
High Light:

steel transmission poles

,

utility power pole

69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole



Specification



Products
  • 69KV 70FT Transmission Line Steel Pole in Hot-dip Galvanized on average 100microns
Type
  • Burial Type
Voltage Grade



  • 69KV
Height
  • 70FT( 21340mm) .
Shape
  • Dodecagonal
Material
  • Hot Roll Steel Sheet Q345 Q420 Q460
Wall thickness
  • 5.0mm
Section
  • In two sections
Welding
  • Welding complies with AWS D1.1 standard.
  • CO2 welding or submerged arc auto methods
  • No fissure, scar, overlap, layer or other defects
  • Internal and external welding
  • Ensure 100% complete penetration welds.
Joint
  • Joint with insert mode
Galvanization
  • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123.
Warranty
  • More than 25 years, it is according to installing environment






Description



69KV 70FT Transmission Line Steel Pole in Hot-dip Galvanized on average 100microns



1) Steel materials conform to ASTM A570 with Q345 q420 q460

2) Welding: Welding complies with CSA and AWS, AWS D1.1 standard.

3) Finish: Hot-dip galvanized in accordance with ASTM A123. Min Zinc Coating 86 microns.

4) Pole Height: Transmission pole 70FT

5) Pole Shape: Polygonal Dodecagonal

6) Type: Straight Pole, burial type

7) Surface hot-dip-galvanized and with Bituminous Painting around grounding line.

8) Resistant: against earthquake of 8.8 grade. Wind speed as design.

9) Quality Standard: ISO9001:2000,AAA credit rating

10) Easy install and maintenance


11) Packages: Normally covered by sack or as customer’s requirement.




69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole 0





Accessories:

1. Pole
2. Base Plate
3. Pole Top Cap
4. Butt Bearing Plate
5. Holes
6. CrossArm
7. Grounding Nut & Bolts
8. Anchor Bolts
9. Climbing Rungs
10. Identification Plate
11. Bituminous Painting if needed
12. Hot dip galvanized.


The hot-dip galvanization technique can protect steel pole from corrosion for 50 years.
As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole can be utilized to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.




Production Line

  • Raw material test
  • Cutting
  • Bending
  • Welding (longitudinal )
  • Dimension verify
  • Flange welding
  • Hole drilling
  • Calibration
  • Deburr
  • Galvanization or powder coating or Bituminous painting
  • Recalibration
  • Packages

 69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole 1



FAQ:


1. Port of Loading: Shanghai, China
2. Price term: FOB or CIF.( Please inform the discharge port)
3. Payment Term: 50%TT in deposit, 50%TT before delivery.
4. Delivery: Based on your order quantity. Normally 30 working days after receiving your deposit.



EXW: Poles Cost

FOB: Pole Cost + Land Transportation + Fee on Port

CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight

CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.



69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole 2



Our company mainly produces various steel poles including street lighting pole, electric power pole, traffic signal pole, flag pole, wind power pole and microwave communication tower, etc. Also, we can offer OEM service, and produce the steel tower according to the customer's design and requirement.





Advantages

  • Short Construction Cycle
  • Less Land Occupation
  • Low Overall Cost
  • Easy Installation and Maintenance
  • Weather Resistance
  • Anti-corrosion
  • ODM & OEM are available
  • Capable to Handle Volume Orders
  • Provide Professional Design by Our Experienced R&D Engineer

69KV 70FT Polygonal Dodecagonal Hot dip Galvanized Power Transmission Steel Pole 3
