Jiangsu Baojuhe Science and Technology Co., Ltd.
(previous name Jiangsu Bosheng Steel Poles Co.,Ltd)
Sales & Support:
|
Product Details:
Payment & Shipping Terms:
|
| Material: | Steel Sheet | Surface Treatment: | Hot Dip Galvanized & Powder Coated |
|---|---|---|---|
| Thickness: | 3mm Or Above | Galvanization: | 86um |
| Height: | 5m-12m | Shape: | Conical |
| Color: | White | ||
| High Light: | electrical street light pole,metal light pole |
||
Dural Arm Brackets Galvanized and White Powder Coating Street Ligh Steel Pole
Product Description:
Material
Normally Q235 high quality mild steel sheet. Silicon less than 2%. We have raw material checked in our lab test room after purchasing the steel sheet. We control the quality at the first beginning.
Shape of Pole
Round conical; Octagonal conical; Straight square; Tubular stepped; Polygonal
Shafts are made of steel sheet that folded into required shape and welded longitudinally by automatic arc welding machine
Brackets
Double brackets are in the shape and dimension as per customer's requirement
Welding
Welding confirms with international welding standard of CWB. No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects.
Base plate mounted
Base plate is square in shape with slotted holes for anchor bolts and dimension as per customer's requirement
Ground mounted
The length buried underground as per customer's requirement
Galvanizing
Hot dip galvanization with thickness of 80-100µm average. Inside and outside surface anti-corrosion treatment by hot dipping acid. Zinc coating is more than 85 um thick, which is in accord with GB/T13912-92 standard.
Specifications
| Height | 5 m to 12m |
| Application | Road ,Street, Highway, etc |
| Shape | Conical |
| Lamp Power | 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz |
| Arm | Double |
| Lighting Fixture | IP 65 |
| Working Atmosphere of Lighting Fixture | -35℃~+45℃ |
| Surface Treatment | Hot dip galvanized with ASTM A 123, color as request. |
| Safety | Against earthquake of 8 grade |
| Wind Speed | 160 Km/Hour |
| Min Yield Strength | 355 mpa |
| Min Ultimate Tensile Strength | 490 mpa |
| Max ultimate tensile strength | 620 mpa |
| Standard | ISO 9001 |
| Thickness | 3mm or as request |
Manufacturing
Our penetration rate is above 95%.
Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All insure us to produce steel poles with best quality.
After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.
FAQ
1. Are you a manufacturer or a trading company?
A:We are the direct factory manufacturer and the trading company.
2. Where is your company located?
A:Our factory is located in Industrial Zone, Heqiao Town, Yixing District, Wuxi City, Jiangsu Province, China(mainland).
3. What are your main products?
A:Our main products are electric poles, street lighting poles, high mast pole, telecommunication tower poles, traffic signal poles, wind generation poles, etc.
4. What's your nearest port?
A: The nearest port is Shanghai Port. We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
5. What's your payment term?
A: Normally 30% deposit and rest by TT before shipping. Or L/C.
6. What's your delivery time?
A: Normally within 15 working days. If our factory is busy and your quantity is large, then around one month.
