Home ProductsPower Transmission Pole

69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load

Certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
I'm Online Chat Now

69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load

69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load
69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load

Large Image :  69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load

Product Details:
Place of Origin: China
Brand Name: JSBS
Certification: ISO9001:2008
Model Number: BS/PT - 24
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Use sack to pack the poles or as customers' requests.
Delivery Time: 15 - 25 work days
Payment Terms: D/P, L/C, T/T, Western Union
Supply Ability: 2500 Ton per month
Detailed Product Description
Design Load: 1885KGF Life Time: More Than 30 Years
Material: Steel Q420 Connection: Slip Joint
Zinc Coating: Min 86μm Galvanized: ASTM A 123
Shape: Dodecagonal Finishing: Hot Dip Galvanized
High Light:

steel transmission poles

,

utility power pole

69KV 70FT Galvanized Electric Sub Transmission Steel Pole in Load 1885KGFTesting



Specification




Products
  • 69KV 70FT Galvanized Electric Sub Transmission Steel Pole in Load 1885KGFTesting
Type
  • Burial Type
Voltage Grade



  • 69KV
Height
  • 70FT( 21340mm) .
Shape
  • Dodecagonal
Material
  • Hot Roll Steel Sheet Q420
Wall thickness
  • 5.0mm
Section
  • In two sections
Welding
  • Welding complies with AWS D1.1 standard.
  • CO2 welding or submerged arc auto methods
  • No fissure, scar, overlap, layer or other defects
  • Internal and external welding
  • Ensure 100% complete penetration welds.
Joint
  • Joint with insert mode
Galvanization
  • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123.
Warranty
  • More than 25 years, it is according to installing environment






Description




1) Steel materials conform to ASTM A570 with Q420

2) Welding: Welding complies with CSA and AWS, AWS D1.1 standard.

3) Finish: Hot-dip galvanized in accordance with ASTM A123. Min Zinc Coating 86 microns.

4) Pole Height: Transmission pole 70FT

5) Pole Shape: Polygonal Dodecagonal

6) Type: Straight Pole, burial type

7) Surface hot-dip-galvanized and with Bituminous Painting around grounding line.

8) Resistant: against earthquake of 8.8 grade. Wind speed as design.

9) Quality Standard: ISO9001:2000,AAA credit rating

10) Easy install and maintenance


11) Packages: Normally covered by sack or as customer’s requirement.


12) Voltage: 69KV





Accessories:

1. Pole
2. Base Plate
3. Pole Top Cap
4. Butt Bearing Plate
5. Holes
6. CrossArm
7. Grounding Nut & Bolts
8. Anchor Bolts
9. Climbing Rungs
10. Identification Plate
11. Bituminous Painting if needed
12. Hot dip galvanized.




69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load 0



Company Introduce:

Through the efforts of the company staff, the support and cooperation from all over the world. Our factory has been exporting the steel poles to the Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good exporting experience and with 1 container exported per day on average.



Production Line

  • Raw material test
  • Cutting
  • Bending
  • Welding (longitudinal )
  • Dimension verify
  • Flange welding
  • Hole drilling
  • Calibration
  • Deburr
  • Galvanization or powder coating or Bituminous painting
  • Recalibration
  • Packages

 69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load 1







FAQ



1. What is the MOQ order for your Pole?

For the distribution of steel poles, MOQ is one container. For the transmission, pole is 1 pcs.



2. Can I use LCL container Loading?

Sure. We can load on LCL.



3. Can you supply sample poles?

Of course, we can delivery the sample poles for customers to test.



4. Can I get a lower price if I make the large order?

Of course! Cheaper prices with a large order.



5. What is the payment term?

30% as deposit in advance and 70% before delivery. Or LC at sight. Or D/P.

Or we can discuss with others payment term.





 69KV 70FT Galvanized Electric Sub Steel Power Transmission Pole 1885KG Load 2


Our company mainly produces various steel poles including street lighting pole, electric power pole, traffic signal pole, flag pole, wind power pole and microwave communication tower, etc. Also, we can offer OEM service, and product the steel tower according to the customer's design and requirement.
