Galvanized square tubing Overhead Line Electrical Power Pole custmised Color

Certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
China Jiangsu Baojuhe Science and Technology Co.,Ltd certification
I'm Online Chat Now

Galvanized square tubing Overhead Line Electrical Power Pole custmised Color

Galvanized square tubing Overhead Line Electrical Power Pole custmised Color
Galvanized square tubing Overhead Line Electrical Power Pole custmised Color

Large Image :  Galvanized square tubing Overhead Line Electrical Power Pole custmised Color

Product Details:
Place of Origin: Jiangsu, China
Brand Name: JSBS
Certification: ISO9001:2008
Model Number: Q345
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 30-300 per set
Packaging Details: as required
Delivery Time: within 15 work days
Payment Terms: T/T, L/C
Supply Ability: 200 set per day
Detailed Product Description
Surface: Hot Dip Galvanized Application: Electricity Transmission
Welding: Penetration Above 95% Material: Q345
Silicon: Less Than 2% Service Life: Over 30 Years
Packing: As Request
High Light:

electrical service pole

,

power transmission poles

Tubular Hot-dip Galvanized Overhead Line Q345 Steel Electrical Power Pole



Description:



Electric steel poles have been a new kind of equipment for erecting power lines in recent years. They are replacing the traditional concrete electric poles step by step. Because their advantages are outstanding.



1. They need less occupied area. Nowadays, land price is getting more and more expensive with more and more population. While steel poles only take 1/3 area of the self-supporting towers. This makes steel poles the first option of power transmission. They take less occupation expenditure.



2. Pole parts are not easy to be stolen. For the traditional concrete poles, pole parts like anchor bolts are easy to be stolen, which is one of the biggest problems for the safe operation of the power transmission. But steel poles are whole planted or flange connected, which prevents the parts from being stolen.



3. It's easy to produce, assemble and construct. This advantage increases efficiency and shortens the time limit for the project.



4. Compared with traditional concrete poles, steel poles are Small and exquisite. This meets the requirement of the urban landscape in most cities.



Type Straight Pole, Tensile Pole, Turn Pole
Suit for Electricity Network
Shape Tubular
Material Steel
Tolerance of dimension +- 2%
Power 10 KV ~550 KV
Safety Factor Safety factor for conducting wine : 8
Design Load in Kg 300~ 1000 Kg appliced to 50cm from the top pole
Marks Name plate through rivert or glue, engrave, emboss as per customer requirement
Surface treatment

Hot dip galvanized with ASTM A 123, color as client required.

Joint of Poles

Insert mode,innerflange mode, face to face joint mode

Design of pole Against earthquake of 8 grade
Wind Speed 160 Km/Hour . 30 m /s
Minimum yield strength

345 mpa

Minimum ultimate tensile strength 490 mpa
Max ultimate tensile strength 620 mpa
Standard ISO 9001
Length of per section Within 12m once forming without slip joint
Welding Welding Standard: AWS ( American Welding Society ) D 1.1
Thickness

2.5 mm to 30 mm



Galvanized square tubing Overhead Line Electrical Power Pole custmised Color 0



Manufacturing

We buy the raw materials from famous mill factory here in China. We'll check the elements of the raw material like silicon, carbon, sulfur etc. in our lab test room. If they are unqualified, we'll return them. In this way, we can control the quality from the first beginning.



Our factory offers ODM and OBM service. Of course, it'll be better if you have the drawing and detailed specifications of the steel poles. So we can immediately calculate the weight and give you the exact quotation.



Hot dip galvanizing Standard Steel thickness/mm Mean coating thickness/μm Metallic element Content
Pole shafts, cross arms&bolted on accessories ASTM A123/A123M-15 AS/NZS 4680 >6 85

Mn



0.25%-0.40%



<3-6 70
1.5-3 55

Cu



<0.15%



<1.5 55
Bolts,nuts&washers

GB/T 5267.3-2008

(ISO 10684-2004)

_____ ≥ 54 P

<0.025%



Foundation bolts ASTM A153/A153M-09 _____ ≥ 54

S



<0.03%

Galvanized square tubing Overhead Line Electrical Power Pole custmised Color 1



Factory Profile



With over 10 Years of Experience/ Capable to Handle Volume Orders

Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.


Founded in 2005, Jiangsu Bosheng Steel Poles Co. Ltd (JSBS) specializes in manufacturing various steel structures. We manufacture a variety of products like Transmission Poles and Substation Structures for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telcommunication poles for the telecommunication industry; Traffic Poles & Camera Poles & Sign Structures for transportation Industry and Advertising Industry.
